DIGITAL SERVO
 Click to enlarge
|
|
| Control System: | PWM Pulse Width Control |
| Processor: | Digital IC |
| Required Pulse: | 3 to 5 V Peak to Peak Square Wave |
| Working frequence: | 760 μs /660 Hz |
| Rotation angle sensor: | Precision Potentiometer |
| Rotation: | Left Rotation: 60° , Right Rotation: 60° |
| Voltage: | 3.5V to 7.4V |
| Temperature Range: | -20℃ to 70℃ |
| Driver Type: | |
| Operating Angle: | 60 Deg. one side pulse traveling 300μs |
| Direction: | Clockwise/Pulse Traveling 450μs-1050μs |
| Pulse Width Scope: | 450-1050μs |
| Neutral pulse: | 1500μs |
| Speed:(No-load ): | 0.04sec/ 60° @ 4.2V |
| 0.03sec/ 60° @ 6.0V | |
| Torque:(Stall Full load): | 1.00 kg . cm @ 4.2V |
| 1.40 kg . cm @ 6.0V | |
| Idle Current: | 0.018 A/ 4.2V 0.020 A/ 6.0V |
| Running Current: | 0.120 A/ 4.2V 0.130 A/ 6.0V |
| Stall Current: | 0.500 A/ 4.2V 0.800 A/ 6.0V |
| Motor Type: | |
| Bearings: | TOP Ball Bearing |
| Bearing Type: | MR85 (5mm x8mm x2mm) |
| Gear Material: | Chrome-Titanium alloy(7075+6061) |
| Servo case: | ABS |
| Plug: | |
| Connector Wire Length: | 120.00 mm |
| Connector Wire SPEC: | OD1.0mm/30 x 0.08mm 3p x 120mm (JST-1.50mm) |
| Weight: | 9.00 g |
| Dimensions (L x W x H): | 22.00*11.60*22.50 mm |
